N552SP, 2000 Cessna 172SP Skyhawk
N552SP Pilot Operating Handbook
Performance
Specifications:
| AIRFRAME: |
Aluminum |
|
|
| |
Wingspan |
36 ft 1 in |
|
| |
Wing area |
174 sq ft |
|
| |
Length |
27 ft 2 in |
|
| |
Height |
8 ft 11 in |
|
| |
Gross Weight |
2550 lbs |
|
| |
Fuel Capacity |
53 gal usable |
|
| PROPELLER: |
Fixed Pitch |
2 blades |
76 in diam |
| ENGINE: |
Lycoming |
IO-360-L2A |
180 HP @ 2700 rpm |
| PERFORMANCE: |
Never Exceed Speed (Vne) |
160 kts |
|
| |
Cruise Speed (75% power) |
117 kts |
|
| |
Rate of Climb (Sea Level) |
710 fpm |
|
| |
Service Ceiling |
14,000 ft |
|
| |
Stall Speed (flaps up) |
53 kts |
|
| |
Stall Speed (flaps extended) |
48 kts |
|
| |
Best Rate of Climb (Vx) |
74 kts |
|
| |
Best Angle of Climb (Vy) |
62 kts |
|
| |
Wing loading |
14.7 lbs/sq ft |
|
| |
Power loading |
14.2 lbs/hp |
|
|
